1. 8 analog audio inputs and 8 analog audio outputs, support free switching between microphone input and line input
2. Each input has a 48V phantom power switch
3. Each input has a feedback suppression function switch, two-speed adjustment
4. With automatic mixing and matrix mixing functions
5. Input 31-band EQ adjustable, output 10-band EQ adjustable
6. USB driver-free automatic connection software, also supports RS232 central control
Provide professional audio and video management services to the world, and strive to create "one-stop" audio and video solutions for different scenarios.
1. DSP chip signal processing 32-bit fixed/floating-point DSP 300MHz
2. Audio system delay < 1ms
3. Digital-to-analog conversion 24-bit
4. Sampling rate 48KHz
5. Analog audio input and output ANALOG AUDIO INPUTS AND OUTPUTS
6. Input channel 8 balanced inputs. Mic/line level
7. Audio interface 3.81 mm Phoenix plug, 12-pin
8. Input impedance 11.5KΩ
9. Maximum input level 14dBu/Line, -7dBu/Mic
10. Phantom power +48VDC, 10mA, each channel configuration
11. Output channel 8 balanced outputs, line level
12. Output impedance 150Ω
13. Audio performance specifications
14. Frequency response curve 20Hz-20kHz(+-0.5dB)/Line
15.20Hz-20kHz(+-1.5dB)/Mic
16.THD+N -90dB(@12dBu,1kHz,A-wt)/Line
17.-86dB(@-7dBu,1kHz,A-wt)/Mic
18.Signal-to-noise ratio 105dB(@12dBu,1kHz,A-wt)/Line
19.95dB(@-7dBu,1kHz,A-wt)/Mic
20.CONNECTION AND DISPLAY COMMUNITICATION PORTS AND INDICATORS
21.USB Micro-B type, driver-free
22.RS232 Serial port communication
23.TCPIP network port RJ-45, Optional
24.Indicator Power, Link, +48V, input and output audio signals
25.Electrical and physical parameters ELECTRICAL AND PHYSICAL
26.Power supply range AC100V---240V 50/60 Hz
27.Dimensions 44mmx483mmx210mm
28.Net weight 2.8kg
29.Operating temperature -20℃--80℃
30.Cooling system Built-in fan
